Provide design, installation, and commissioning services of BOP system for hydrogen electrolyzer such as AWE, PEM, and AEM

BOP system solutions

Technological advantages and innovations
The team possesses extensive experience in the design, installation, and commissioning of over dozens of sets of AWE, PEM, and AEM BOP systems
  • Efficient and integrated design
  • High safety factor
  • The product has a low waste rate
  • Anti-ion contamination technology
  • Faster startup speed
  • Scientific flow field design

BOP system solutions

Function and Positioning
BOP (Balance Of Plant) is the core support system to ensure the efficient and stable operation of the electrolytic cell. It covers all dimensions of modules including power supply, water management, gas treatment, temperature management, monitoring and control.
Component part
  • Water treatment system
  • Gas-liquid separation system
  • Gas purification system
  • Power supply system
  • Intelligent control system

The Core Subsystem

Gas-Liquid Separation System
Separates the gas-liquid mixture generated by the Electrolyzer, enabling the liquid to recirculate within the system while directing the gas to purification equipment after cooling and droplet removal.
Gas Purification System
Purifies gases to meet target purity specifications
Water Treatment System
Water serves as the reactant in the electrolysis process. Pre-treatment\ Reverse Osmosis(RO)\ Electrodeionization(EDI)

The Core Subsystem

Power Supply System
Transformer

Regulates output voltage based on electrolyzer stack requirements

Rectifier

Converts AC input to stabilized DC output

Monitoring Module

Monitors stack voltage/current in real-time with protective functions

The Core Subsystem

Control System
PLC/DCS

Negative meter data acquisition, logic control.

Human-machine Interface (HMI)

It provides an operation interface to facilitate users' understanding of the system's operating status and operations

Communication interface

It realizes data exchange with the upper computer or other systems
